A modern airplane’s fuselage is made from multiple sheets of different composite materials, like so many layers in a phyllo-dough pastry.
Once these layers are stacked and molded into the shape of a fuselage, the structures are wheeled into warehouse-sized ovens and autoclaves, where the layers fuse together to form a resilient, aerodynamic shell.
MIT engineers have developed a method to produce aerospace-grade composites without the enormous ovens and pressure vessels. The technique may help to speed up the manufacturing of airplanes and space vehicles and other large, high-performance composite structures, such as blades for wind turbines.
==
==
Brian Wardle, professor of aeronautics and astronautics at MIT, explained the importance of the breakthrough: "If you’re making a primary structure like a fuselage or wing, you need to build a pressure vessel, or autoclave, the size of a two- or three-story building, which itself requires time and money to pressurise.
"These things are massive pieces of infrastructure. Now we can make primary structure materials without autoclave pressure, so we can get rid of all that infrastructure."
Professor Wardle’s co-authors on the paper are lead author and MIT post doctoral candidate Jeonyoon Lee, and Seth Kessler of Metis Design Corporation, an aerospace structural health monitoring company based in Boston.
Lee led the team, along with another member of Professor Wardle’s lab, in creating a method to make aerospace-grade composites without requiring an oven to fuse the materials together.
PROMOTED CONTENT
Instead of placing layers of material inside an oven to cure, the researchers essentially wrapped them in an ultra-thin film of carbon nanotubes (CNTs).
When they applied an electric current to the film, the CNTs, like a nanoscale electric blanket, quickly generated heat, causing the materials within to cure and fuse together.
With this out-of-oven, or OoO, technique, the team was able to produce composites as strong as the materials made in conventional airplane manufacturing ovens, using only 1 per cent of the energy.
The researchers next looked for ways to make high-performance composites without the use of large, high-pressure autoclaves — building-sized vessels that generate high enough pressures to press materials together, squeezing out any voids, or air pockets, at their interface.
Professor Wardle explained, "There’s microscopic surface roughness on each ply of a material, and when you put two plys together, air gets trapped between the rough areas, which is the primary source of voids and weakness in a composite. An autoclave can push those voids to the edges and get rid of them."
Researchers including Professor Wardle’s group have explored “out-of-autoclave”, or OoA, techniques to manufacture composites without using the huge machines.
However, most of these techniques have produced composites where nearly 1 per cent of the material contains voids, which can compromise a material’s strength and lifetime. In comparison, aerospace-grade composites made in autoclaves are of such high quality that any voids they contain are neglible and not easily measured.
Part of Professor Wardle’s work focuses on developing nanoporous networks — ultra-thin films made from aligned, microscopic material such as carbon nanotubes that can be engineered with exceptional properties, including colour, strength and electrical capacity.
The researchers wondered whether these nanoporous films could be used in place of giant autoclaves to squeeze out voids between two material layers, as unlikely as that may seem.
A thin film of carbon nanotubes is somewhat like a dense forest of trees, and the spaces between the trees can function like thin nanoscale tubes, or capillaries. A capillary such as a straw can generate pressure based on its geometry and its surface energy, or the material’s ability to attract liquids or other materials.
The researchers proposed that if a thin film of carbon nanotubes were sandwiched between two materials, then, as the materials were heated and softened, the capillaries between the carbon nanotubes should have a surface energy and geometry such that they would draw the materials in towards each other, rather than leaving a void between them.
Lee calculated that the capillary pressure should be larger than the pressure applied by the autoclaves.
The researchers tested their idea in the lab by growing films of vertically aligned carbon nanotubes using a technique they previously developed, then laying the films between layers of materials that are typically used in the autoclave-based manufacturing of primary aircraft structures.
They wrapped the layers in a second film of carbon nanotubes, which they applied an electric current to to heat it up. They observed that as the materials heated and softened in response, they were pulled into the capillaries of the intermediate CNT film.
The resulting composite lacked voids, similar to aerospace-grade composites that are produced in an autoclave. The researchers subjected the composites to strength tests, attempting to push the layers apart, the idea being that voids, if present, would allow the layers to separate more easily.
Professor Wardle added, "In these tests, we found that our out-of-autoclave composite was just as strong as the gold-standard autoclave process composite used for primary aerospace structures. There are ways to make really large blankets of this stuff, and there’s continuous production of sheets, yarns and rolls of material that can be incorporated in the process."
He plans also to explore different formulations of nanoporous films, engineering capillaries of varying surface energies and geometries, to be able to pressurise and bond other high-performance materials.
"Beyond airplanes, most of the composite production in the world is composite pipes, for water, gas, oil, all the things that go in and out of our lives. This could make making all those things, without the oven and autoclave infrastructure," Professor Wardle added.
This research was supported, in part, by Airbus, ANSYS, Embraer, Lockheed Martin, Saab AB, Saertex and Teijin Carbon America through MIT’s Nano-Engineered Composite aerospace Structures (NECST) Consortium.
